Outdoor antenna Emme Esse 216, FM, ICE, dipole H-V

EMME ESSE 216FM antenna is a dipole for FM radio reception with horizontal and vertical polarization. Easy to install. It enables reception of both Czech Radio's horizontal polarization transmitters and private VHF II transmitters, mainly broadcast with vertical polarization. The antenna is manufactured in the ICE series of aluminum alloy with antioxidant coating and passivation, plastic parts are white.


Technical parameters :

- working band : VHF II FM (87.5 - 108 MHz)
- number of elements : 1
- gain : 1 dB
- radiation angle in horizontal plane : 360 °
- anterior-posterior ratio : 0
- Output impedance : 75?
- Connection on built-in connector : Ff
- weight : 0,6 kg
- wind load on the mast : 3.3 kg
- max. diameter of the mast : 55 mm
