BMS for 8S LiFePO4 cells (25.6V) 20A
BMS modul - konfigurace 8S pro LiFePO4 články, jmenovité napětí 25,6V, max. vybíjecí proud 20A, ochrana proti nadproudu (nabíjení >10A, vybíjení >20A), ochrana proti přebití při napětí 3,75V na článek, ochrana proti podvybití při 2,2V na článek, teplotní ochrana aktivní pod -7°C a nad 70°C, společný port pro nabíjení i vybíjení (Common Port)
Will be restocked
Expected shipping:
26.02.2026
at our place
Regular price
389,00 Kč
321,49 Kč
excl. VAT
Unit price
/
Unavailable
HADEX | SKU:
09830278
BMS for 8S LiFePO4 cells (25.6V) 20A
Regular price
389,00 Kč
321,49 Kč
excl. VAT
Unit price
/
Unavailable
Product description
BMS for LiFePO4 18650 and other LiFePO4 batteries.
Technical parameters.
- overcurrent protection — 18650 Li-ion battery will stop charging when the current exceeds 10A and stop discharging when the current is over 20A
- over-discharge protection — 18650 LiFePO4 battery will stop charging when its voltage reaches 3.75V and stop discharging when its voltage reaches 2.2V
- temperature protection – BMS stops charging at temperatures lower than -7 °C and higher than 70 °C
Common port: common port for charging / discharging
Technical parameters.
- overcurrent protection — 18650 Li-ion battery will stop charging when the current exceeds 10A and stop discharging when the current is over 20A
- over-discharge protection — 18650 LiFePO4 battery will stop charging when its voltage reaches 3.75V and stop discharging when its voltage reaches 2.2V
- temperature protection – BMS stops charging at temperatures lower than -7 °C and higher than 70 °C
Common port: common port for charging / discharging
