Gateway SONOFF Dongle Max ZigBee
ZigBee gateway - tři možnosti připojení: Ethernet (PoE), Wi-Fi nebo USB, funkce koordinátora, směrovače nebo koncového zařízení ZigBee, automatická detekce konfigurace, kompatibilní s Home Assistant a Zigbee2MQTT, montáž na stůl nebo zeď, vhodná pro domácí i kancelářskou automatizaci, napájení přes PoE nebo USB
Last piece
Expected shipping:
15.06.2026
Regular price
1.139,00 Kč
941,32 Kč
excl. VAT
Unit price
/
Unavailable
SONOFF | SKU:
06445372
Gateway SONOFF Dongle Max ZigBee
Regular price
1.139,00 Kč
941,32 Kč
excl. VAT
Unit price
/
Unavailable
Product description
SONOFF Dongle Max is a powerful ZigBee gateway that allows easy and stable connection of ZigBee devices to Home Assistant or Zigbee2MQTT. Equipped with powerful components, PoE support and three connection options - Ethernet, Wi-Fi or USB - it will work well in various installation conditions.
Versatile connectivity
Dongle Max offers several connection options: via Ethernet with PoE power supply, Wi-Fi or classically - via USB. Thanks to this, you can place the gateway in the most convenient place - on a table, on a wall, etc. The absence of restrictions means it is easier to adapt to the layout of your home or office. Dongle Max works with popular open-source platforms and thanks to automatic detection, configuration takes literally a moment. The device supports various functions - it can act as a Zigbee coordinator, router or support Thread RCP. MultiPAN support is also planned in the future - i.e. simultaneous support for Zigbee and Thread.
Powerful components
The gateway uses two proven chipsets: EFR32MG24 for ZigBee and Thread support and ESP32 for Wi-Fi communication. This combination guarantees stability, fast data transfer and low power consumption - which is especially important if you plan to expand your smart installation.
Thoughtful solutions
From the local web console, you can view the device status, update firmware, change settings or configure the web hook - without installing additional software. Everything is done via a simple interface that you can access from any device on your local network. In addition, it is possible to remotely switch firmware, use the web hook for notifications and backups, manage multiple Dongle Max devices simultaneously or adjust the color and brightness of the LED indicators.
Technical parameters:
Input voltage: 5V / 1A via Type-C connector or 48V / 0.25A via PoE port
Wireless connection: Zigbee 3.0, Wi-Fi IEEE 802.11b/g/n 2.4GHz
Operating temperature range: -10 °C to 60 °C
Case material: Aluminum, PC + ABS
USB connector: Type C
Network connector: RJ45
Color: Gray
Package contents:
ZigBee gateway
USB-A to USB-C cable
Mounting bracket
2x tapes
Mounting hardware (4x dowels, 4x screws)
User manual
Versatile connectivity
Dongle Max offers several connection options: via Ethernet with PoE power supply, Wi-Fi or classically - via USB. Thanks to this, you can place the gateway in the most convenient place - on a table, on a wall, etc. The absence of restrictions means it is easier to adapt to the layout of your home or office. Dongle Max works with popular open-source platforms and thanks to automatic detection, configuration takes literally a moment. The device supports various functions - it can act as a Zigbee coordinator, router or support Thread RCP. MultiPAN support is also planned in the future - i.e. simultaneous support for Zigbee and Thread.
Powerful components
The gateway uses two proven chipsets: EFR32MG24 for ZigBee and Thread support and ESP32 for Wi-Fi communication. This combination guarantees stability, fast data transfer and low power consumption - which is especially important if you plan to expand your smart installation.
Thoughtful solutions
From the local web console, you can view the device status, update firmware, change settings or configure the web hook - without installing additional software. Everything is done via a simple interface that you can access from any device on your local network. In addition, it is possible to remotely switch firmware, use the web hook for notifications and backups, manage multiple Dongle Max devices simultaneously or adjust the color and brightness of the LED indicators.
Technical parameters:
Input voltage: 5V / 1A via Type-C connector or 48V / 0.25A via PoE port
Wireless connection: Zigbee 3.0, Wi-Fi IEEE 802.11b/g/n 2.4GHz
Operating temperature range: -10 °C to 60 °C
Case material: Aluminum, PC + ABS
USB connector: Type C
Network connector: RJ45
Color: Gray
Package contents:
ZigBee gateway
USB-A to USB-C cable
Mounting bracket
2x tapes
Mounting hardware (4x dowels, 4x screws)
User manual
