Smart Switch SONOFF MINI-DIM WiFi Matter

The Sonoff MINI-DIM WiFi is an ultra-compact, recessed smart dimmer that turns an ordinary switch into an advanced smart home system. It offers on/off switching, 0-100% continuous dimming, scenes, scheduling, remote and voice control, energy monitoring and full integration with the Matter ecosystem via WiFi. It fits most installations, supports multiple lighting types, and fits in a standard recessed box. It's a quick way to add "smart" features to your existing installation - without cutting into walls or replacing lamps.

Matter and efficient WiFi - one device, all platforms
With support for the Matter standard, MINI-DIM works seamlessly with Apple Home, Google Home, Amazon Alexa, SmartThings and Home Assistant. You don't have to choose one system or worry about compatibility - the module works wherever you are. At the heart of the device is the energy-efficient ESP32-C3 chip, which provides fast operation, stable 2.4GHz WiFi connectivity and OTA updates. The MINI-DIM can acquire new features and enhancements with subsequent software releases, keeping it up-to-date for years to come.

Smooth, flicker-free dimming - light exactly as you want it
The back-edge dimming technology ensures exceptionally smooth brightness control without flickering, buzzing or voltage fluctuations. The light adapts naturally to the situation - strong for work, soft for relaxation, atmospheric in the evening. Comfort for the eyes and a more pleasant atmosphere in every room. Built-in power metering allows you to check how much electricity the lighting is consuming. This makes it easy to optimise lamp operation, eliminate unnecessary losses and reduce bills.

Wide compatibility with lamps - install and it works
There is no need to replace lamps or adapt the installation to a specific type of lighting. MINI-DIM works seamlessly with dimmable LED lamps up to 200 VA, conventional incandescent and halogen lamps up to 400 W and dimmable electronic transformers up to 200 W. This means complete flexibility of use - from subtle decorative lighting to powerful main lighting in the living room or kitchen - without compromise or additional cost.

Intelligent control - app, voice, calibration and LAN
From the eWeLink app, you can remotely turn lights on and off, adjust brightness, set timers, scenes and automation, and control energy consumption. Voice assistant support allows you to control your lighting with a command - no need to go to the switch. Built-in auto calibration automatically adjusts the dimming range to the lamp connected, eliminating flicker and dead zones of brightness. Plus, the control works locally on a LAN, so the device responds instantly even without internet access - faster, more stable and whenever you need it.

Robust design and reliable electronics
The V-0 fire-resistant PC plastic housing combined with high-quality electronic components ensures safe and stable operation. Built-in NTC temperature sensor, overheat protection, surge protection and shock protection effectively protect the installation and connected lighting. CE and RoHS certification confirm compliance with European safety standards.

Easy installation, quick pairing, immediate effect
Connect the wires, pair the devices in the app or with Code Matter and you're done. MINI-DIM works with both conventional wall switches and completely wirelessly. With dimensions of only 45 × 39.4 × 16.8 mm, the MINI-DIM easily fits behind a traditional switch. In just a few minutes, you can turn your traditional lighting into an intelligent system that improves your everyday comfort.

Specifications:

Communication standard.
Wireless Connection: WiFi 2.4 GHz IEEE 802.11 b/g/n
Control System (MCU): ESP32-C3
Power supply voltage: 220-240 V AC
Frequency: 50 Hz
Maximum resistive load: 400 W
Maximum LED load: 200 VA
Supported lighting types: Dimmable LED, traditional incandescent, halogen, electronic transformers
Dimming range: 0-100%
Brightness Calibration: Automatic
Power consumption monitoring: Yes
Local control via LAN: Yes
Voice control: Yes
Scene and schedule support: Yes
OTA Update: Yes
Neutral wire required: Yes
Housing material: PC plastic, non-flammable
Color: White
Dimensions: 45 × 39.4 × 16.8 mm
Weight: 24.5 g
Recommended wire thickness: 18-16 AWG, copper
Installation location: indoor
Operating temperature: -10 °C to 40 °C
Operating humidity: 5-95% RH, non-condensing
Protection: Overtemperature, overvoltage, NTC temperature protection

Package contents:

MINI-DIM Intelligent Dimmer
User manual
