Smart Switch SONOFF MINI-ZBDIM ZigBee
New
Chytrý ZigBee stmívač - standard Zigbee 3.0, plynulé stmívání 0–100 %, max. výkon 400W, funkce síťového routeru pro rozšíření dosahu Zigbee sítě, monitorování spotřeby energie, automatická kalibrace, časové plány a scény, kompatibilní s eWeLink a Home Assistant, ovládání hlasem, instalace do zapuštěné krabice, nadproudová a tepelná ochrana
In stock 4 pcs
Expected shipping:
16.06.2026
Regular price
689,00 Kč
569,42 Kč
excl. VAT
Unit price
/
Unavailable
SONOFF | SKU:
06446463
Smart Switch SONOFF MINI-ZBDIM ZigBee
Regular price
689,00 Kč
569,42 Kč
excl. VAT
Unit price
/
Unavailable
Product description
The Sonoff MINI-ZBDIM Zigbee is a smart, recessed controller and dimmer that turns ordinary lighting into an advanced smart home system. It offers infinite brightness adjustment from 0 to 100%, on/off, scheduling, timers, scenes, energy monitoring and app and voice control. It runs on the Zigbee 3.0 standard, acts as a network router, increases the range of the entire installation, and works with many gateways and platforms, from eWeLink to Home Assistant. Its small size, high power (up to 400W), automatic calibration and extensive security features make it a reliable solution for any modern home.
Zigbee 3.0 - stable connectivity and greater range for the entire network
Zigbee technology ensures fast response times, low power consumption and independence from WiFi. The MINI-ZBDIM acts as a router, amplifying the signal and extending the range of the mesh network, helping other devices to communicate more efficiently even in larger apartments and houses. The result? More stable operation of the entire system and fewer dead zones.
Unlimited compatibility
The module easily connects to popular Zigbee gateways such as ZBBridge-P, ZBBridge-U, NSPanel Pro, iHost, as well as USB dongles for Home Assistant (ZBDongle-P/E, Dongle Plus MG24, Dongle Lite MG21 or Dongle Max). Integration with eWeLink, Home Assistant (ZHA, Zigbee2MQTT) and even Apple Home via Matter Bridge gives you the freedom to choose your platform and develop your system without being tied to one ecosystem.
Smooth dimming without flickering
Advanced trailing edge dimming technology provides smooth brightness control without flickering or buzzing. MINI-ZBDIM works with dimmable LEDs up to 200 VA, traditional and halogen bulbs up to 400 W and electronic transformers up to 200 W. One device can handle both soft night lighting and full living room or kitchen lighting.
App, voice and scene control - intelligence for everyday use
In the app, you can set schedules, timers, inching mode, blackout status, lighting and automation scenarios tailored to your lifestyle. Voice control lets you change the brightness or turn off lights without getting off the sofa, and built-in energy metering helps you control costs. Plus, automatic and manual brightness calibration adjusts the dimming range to the specific lamp, eliminating the hassle of minimal light levels.
Miniature design, maximum possibilities in a recessed box
With compact dimensions of 45 × 39.4 × 16.8 mm, the module fits easily into standard EU, 86 and 120 mounting boxes. Install it behind a traditional switch and maintain the classic look of your wall, while getting full smart functionality without renovations or additional surface mounted devices.
Premium safety and durability - reliability for years to come
Fire-resistant PC plastic housing (class V-0), NTC temperature sensor, overheat protection, surge protection and solid wire terminals guarantee stable and safe operation even under high loads. The powerful EFR32MG21 chip ensures reliable Zigbee communication, while CE and RoHS certification and a two-year warranty confirm quality you can rely on every day.
Specifications:
Zigbee 3.0 communication standard.
Radio protocol: IEEE 802.15.4
Role in Zigbee network: router (mesh signal amplification)
Control System (MCU): EFR32MG21
Power supply voltage: 220-240 VAC
Frequency: 50 Hz
Maximum resistive load: 400 W
Maximum LED load: 200 VA
Supported lighting types: Dimmable LED, traditional incandescent, halogen, electronic transformers
Trailing-edge technology (smooth, flicker-free)
Dimming range: 0-100%
Brightness calibration: automatic and manual
Energy monitoring: yes
App control: Yes (eWeLink)
Voice Control: Yes (via compatible hubs and platforms)
Scene and Schedule Support: Yes
Inching mode (automatic shutdown after a set time): Yes
Power failure memory: Yes
External switch support: Yes
OTA Update: Yes
Neutral wire required: Yes
Housing Material: PC plastic, non-flammable (V-0 rating)
Color: White
Dimensions: 45 × 39.4 × 16.8 mm
Weight: 24.5 g
Recommended wire thickness: 18-16 AWG, copper
Compatible mounting boxes: EU, 86, 120
Mounting location: indoor
Operating temperature: -10 °C to 40 °C
Operating humidity: 5-95% RH, non-condensing
Protection: Overtemperature (NTC), overvoltage, surge protection
Package contents:
Sonoff MINI-ZBDIM Intelligent Dimmer
User Manual
