Wallbox Grohm GW11CSL 11kW 3f Type 2

Green Charger Grohm GW11CSL – Three-Phase Charging Station 11 kW (Smart Version) Made in Italy, it combines smart technologies with compact design and intuitive operation.

The Green Charger Grohm GW11CSL is a three-phase 11 kW charging station ideal for both home use and commercial premises with higher demands on EV charging. This smart model is equipped with an intuitive touch display and a Web App for managing the charging process. It supports dynamic load balancing, which optimizes the use of available electrical power according to household consumption. The GW11CSL also allows integration with photovoltaic systems, enabling efficient charging from solar energy. Thanks to advanced features such as RFID protection, it is well-suited for shared or public installations.


Product parameters:

- Made in Italy

- 11 kW power (three-phase): Sufficient for fast and efficient EV charging.
- dynamic load balancing: Adjusts charging based on current household consumption.
- touch display & Web App: Simple monitoring and remote management.
- photovoltaic mode: Use solar energy to reduce charging costs.
- RFID protection: Secure access using RFID key or card.
- scalability: Master/slave functionality to connect multiple stations.


Technical Specifications:

- power: 11 kW (three-phase)
- input voltage: 400V AC (three-phase)
- frequency: 50/60 Hz
- max current: 16 A
- energy metering: Integrated MID meter (±5%)
- power modulation: Toroid coil (three-phase)
- DC leakage current: 6 mA
- protections: Short-circuit, overload, overvoltage, DC leakage
- enclosure rating: IP54 (water and dust resistant)
- mechanical resistance: IK07
- operating temperature: -20 °C to 45 °C
- humidity: 5% to 95%
- connection: Type 2 connector, 5 m cable
- communication: Ethernet, Wi-Fi, RS485, OCPP
- master/slave support: Yes
- display: 2.8" touchscreen + LED status indicators
- RFID: Supports up to 20 tags (card and key included)
- web App: Remote control and monitoring
- solar mode (SOLAR): EXCLUSIVE: Charging only from PV system, PARTIAL: Minimal current even without solar production
- dimensions: 155 × 210 × 92 mm
- weight: 4 kg
-installation: Wall-mounted or floor-mounted (with kit)

Package: 1 unit
